B Tech coaching in Delhi for Analog Electronics-2

Tejas Engineers Academy offers top quality B Tech coaching in Delhi for Analog Electronics 2. Following is the syllabus of Analog Electronics

Unit -1:-

Introduction to op-amps:- Differential amplifier using BJT, Block diagram of op amp, Pin diagram of 741 IC, Characteristics of ideal op amp, Equivalent circuit of op amp, ideal voltage transfer curve, op amp ac and dc parameters.

Building blocks of analog ICs: Differential amplifier using single and two op amps, virtual ground, circuit for improving CMRR, Wilson and widlar current mirrors, Active loads, level shifters and output stages  instrumentation amplifier using op amp.

Unit:-2

Linear  and nonlinear waveshaping: Inverting and noninverting amplifiers, Voltage follower, Difference amp, adders, voltage to current converter with floating and grounded load, Current to voltage converter, practical integrator and differentiator, clipping and claping, circuits, comparators, log / antilog circuits using op amps, precision rectifiers, peak detector, inverting and non inverting shmitt trigger circuits.

Waveform generators sine wave generators, phase shift ,wein bridge, Hartley and colpitts, barkhausen criteria of oscillations, conditions for oscillation, crystal oscillator.

Tejas Engineers Academy is no. 1 in  B.Tech coaching Institutes  in Delhi for Analog Electronics -2.

Unit:-3

Waveform generators, square and triangular waveform generators, determine period and frequency, sawtooth wave generator, astable multivibrator, monostable and bistable multivibrators.

Active RC Filters: Idealistic response of filters {LPF, BPF, HPF, BRF}, Butterworth and chebyshev approximation filter functions, All pass, Notch filter.

Unit -4

Introduction to 555 timer IC, Functional and block diagram of 555 timer, application of 555 timer as stable and monstable multivibrators, operational transcunductance amplifier, OTA filter, OTA integrator and differentiator, introduction to current conveyor, IC phase locked loop



Tejas Engineers Academy is offering B Tech coaching in Delhi for Differential amplifier circuit. Lecture is scheduled tomorrow. Following is the brief details of the lecture



Differential amplifier circuit configurations:-

The configurations are categorized on the basis of the number of inputs and the way an output voltage is measured. Accordingly, differential amplifier configurations may be classed as follows:

1.      Dual input, balanced output differential amplifier configuration.

2.      Dual input, unbalanced output differential amplifier configuration.

3.      Single input balanced output differential output amplifier configuration.

4.      Single input unbalanced output differential amplifier configuration.

When both the inputs are used the configuration is said to be dual input, otherwise single input. On the other hand, when the output voltage is measured between two collectors, it is referred to as a balanced output, because both collectors C1 and C2 are at the same dc potential w.r.t. ground. In case the output is measured across any one collector w.r.t ground, the configuration is known as an unbalanced output.

B Tech coaching in Delhi provided at our institute is best in Delhi and we guarantee you the excellent success in analog electronics examination. We cover all major universities. In order to attend full lecture please contact us 9999070890 for all your needs of B.Tech coaching centre in Delhi. We assure you guaranteed success.
